Large Range 550X650MM Working Area UV CO2 Fiber Laser Marking Machine XY Axis Mobile Platform Supports DXF BMP AI Graphic Format

laser type : UV, CO2

working accuracy : 0.02mm

Brand Name : HM

Place of Origin : Hubei, China

cnc or not : Yes

condition : New

configuration : Bench-Top

control software : EZ CAD

control system brand : Other

Cooling System : Water Cooling

feature : Vision System

graphic format supported : AI, BMP, DXF, DXP, LAS

key selling points : Multifunctional

mode of operation : Continuous Wave

warranty : 1 Year

Weight : 350

MOQ : 1

Price : $2,700-4,700

Contact Now

Ltem	Data
Laser power	3w/5w/10w/20w/30w/50w/60w/80w/100w/150w
Laser wavelength	355 nm/1064 nm/1060 nm
Light source selection	Configuration options according to requirements; fiber optic light source, UV light source, CO2 light source
Applicable materials	Choose various light sources (fiber/ultraviolet/CO2) suitable for laser engraving according to the product material.
Laser power selection	UV light source; Ordinary plastic surface laser engraving: 3W/5W. Select Depth laser engraving such as glass/ceramic: 5W/10W(RFH with high fine craftsmanship) Fiber Light Source; Ordinary metal surface laser engraving: 20W/30W/50W. Deep laser engraving: 50W/100W Thinner product cutting: 50W/100W/150w/200w Special materials, plastic product marking options: 20W-MOPA light source CO2 light source; Marking mark; 30w/60w/80w Engraving and cutting; 80w/100w/150w
Processing area	X-Y axis stroke; 200x200-800x800mm or customized for larger range sizes
Power consumption	Fiber light sourceUV light source<1000w CO2 light source<900w
Applicable to light source	UV light source is suitable for: plastic, silica gel, glass, acrylic, ceramics, hollow out the surface of the oxide layer of the product, wood products, paper products, etc. Fiber optic light sources are suitable for: Non-ferrous metal products. Hardware products, gold, silver, copper, aluminum,stainless steel. Some plastic products. CO2 light source is suitable for Paper. Leather. Bamboo and wood products. Garment accessories. Acrylic. Glass. Ceramics. Jade and other fields.

FAQ:

Q: How to choose suitable model?
A: Please provide a photo of the product you used before or advise us your needs, we will give suggestions.

Q: What's your MOQ?

A:Normally one piece. If more, we can talk about discount. We can ship all parts you ordered together.

Q: Can I get discount?
A: The more you order, the more discount you will get.

Q: What is your terms of payment?
A: 100% in advance. Payment>=50000USD, 50% T/T in advance, balance before shipment.

Q: How long is your delivery time?
A: When the order is confirmed, 3-5 working days for the small order, 2-6 weeks for the bulk depending on the quantity and product type.
